VT-LEM07224(i)-M12-MP10
1. Megapixel High Resolution Design
2. Optimized for 1/3” and 1/2” Sensors with Small Pixels
3. Multiple f/# Options for Performance
4. High Cost Performance
Inquire now
Shop now
Product Description
Technical Drawing
Documents & Downloads

General Information

PD No. CP-0095
PD Line M12 Series
Type Standard FA Lens


Optical Specifications

Resolution 10 Mega Pixels
Image Size 1/2.3" CCD/CMOS
Focal length 7.2 mm
Aperture, F/# F2.4
Back Focus 7.23 mm
M.O.D 0.3 m
FOV(D×H×V)

D:57°

H:47°

V:37°

TV Distortion NA
TTL 32.37±0.3 mm
Relative Illumination NA
Iris Fixed
Max Chief Ray Angle NA
Coating Wavelength 400-950 nm


Design

Mount S-mount(M12)
Filter Size NA
Built-in ir-cut NA
Lens Effective Diameter Φ13.3 / Φ7.5
Dimension Φ19 × 26.14±0.3 mm
Working Temperature -10 - 50°C(Operating),-20 - 60°C(Storage)
Weight NA

Standard FA industrial lens


-->
