VT-LEM05425(i)-M12-MP10
1. Megapixel High Resolution Design
2. Optimized for 1/3” and 1/2” Sensors with Small Pixels
3. Multiple f/# Options for Performance
4. High Cost Performance
Inquire now
Shop now
Product Description
Technical Drawing
Documents & Downloads

General Information

PD No. CP-0094
PD Line M12 Series
Type Standard FA Lens


Optical Specifications

Resolution 10 Mega Pixels
Image Size 1/2.3" CCD/CMOS
Focal length 5.4 mm
Aperture, F/# F2.5
Back Focus 6.6 mm
M.O.D 0.2 m
FOV(D×H×V)

D:70°

H:60°

V:46°

TV Distortion -2%
TTL 24.74 mm
Relative Illumination NA
Iris Fixed
Max Chief Ray Angle NA
Coating Wavelength 400-950 nm


Mechanical Parameters

Mount S-mount(M12)
Filter Size NA
Built-in ir-cut NA
Front/Rear Effective Dia. Φ10.9 / Φ6.7
Dimension Φ14 × 18.74 mm
Temperature Range -10- 50°C(Working),-20- 60°C(Storage)
Weight 6.5 g

Standard FA industrial lens


-->
