Information |
||
|---|---|---|
| PD No. | CP-0704 | |
| PD Line | Mars Series | |
Sensor |
||
|---|---|---|
| Sensor Vendor | Gpixel | |
| Sensor | GMAX3265 | |
| Shutter | Global Shutter | |
| Sensor Size | 37.4mm | |
| Sensor Type | CMOS | |
| Resolution | 9344 × px x 7000 px | |
| Pixel size | 3.2 μm × 3.2 μm | |
| Frame Rate | 31 fps | |
| Mono/Color | Mono | |
EMVA Data |
||
|---|---|---|
| Dynamic range | 66.0 dB | |
| Signal-to-Noise Ratio | 40.0 dB | |
Camera Data |
||
|---|---|---|
| Interface | CoaXPress | |
| Pixel Bit Depth | 12 bits | |
| Synchronization |
● Soft Trigger ● Hardware Trigger ● Free Run |
|
| I/O | Opto-isolated input x 3, opto-isolated output x 3, RS232 x 1 | |
| Power Supply | PoCXP / DC 24V | |
Design |
||
|---|---|---|
| Dimension(L x W x H) | 72.0 × 72.0 × 70.0 mm | |
| Lens Mount | M58 | |
| Operating Temperature | -30~80 °C (Storage), -30~50°C (Working) | |
| Weight | 670g | |
Software Environment |
||
|---|---|---|
| Driver&SDK | Frame grabber software complies with CoaXPress protocol | |
| Operating System | Windows | |
| Conformity | Coaxpress and GenICam | |
