MARS25MG-150XM-M42
  1. 25MP @150 fps
  2. CoaXPress uses CXP-12, theoretical bandwidth 4 x 12.5Gbps
  3. Compatible with CoaXPress Protocol, GenlCam Standard, and the third-party software based on these
  4. protocol and standard
  5. Support Windows operating platform
  6. Support PoCXP power supply and DC 24V power supply
Inquire now
Product Description
Technical Drawing
Documents & Downloads

Information

PD No. CP-0704
PD Line Mars Series

Sensor

Sensor Vendor Gpixel
Sensor GMAX0505
Shutter Global Shutter
Sensor Size 1.1”
Sensor Type CMOS
Resolution 5120 × 5120
Pixel size 2.5 μm × 2.5 μm
Frame Rate 150 fps
Mono/Color Mono

EMVA Data

Dynamic range 63.0 dB
Signal-to-Noise Ratio 36.0 dB

Camera Data

Interface CoaXPress
Pixel Bit Depth 10 bits
Synchronization

● Soft Trigger

● Hardware Trigger

● Free Run

I/O Opto-isolated input x 3, opto-isolated output x 3, and RS232 x 1
Power Supply PoCXP / DC 24V

Design

Dimension(L x W x H) 80.0 × 80.0 × 65.3 mm
Lens Mount M42
Operating Temperature -30~80 °C (Storage), -30~50°C (Working)
Weight 890g

Software Environment

Driver&SDK Frame grabber software complies with CoaXPress protocol
Operating System Windows
Conformity CoaXPress,GenICam

Product Specification

Mars Series Industrial Cameras User Manual

Mars Series Industrial Cameras SDK iCentral


-->
