General Information |
||
|---|---|---|
| PD No. | VT-LEMF4028MP29-0.01X | |
| PD Line | Large format | |
| Type | Large format F/T Mount lens | |
|
|
||
|---|---|---|
| Resolution | 30lp/mm 5 MP | |
| Format | 43mm | |
| Focal Length | 40.0 mm | |
| Aperature, F/# | F2.8-22 | |
| Mag. Range | 0.01x-0.25x | |
| Standard Mag. | 0.1x | |
| Flange Back | 46.5mm | |
| Back Focus | 436.7 mm | |
| M.O.D | 0.2 m | |
|
FOV(D×H×V) |
D:65° H:/° V:/° |
|
| TV Distortion | <0.2% | |
| TTL | 89.15 | |
| Relative Illumination | NA | |
| Focus Range | NA | |
| Iris | Manual | |
| Focus | Manual | |
| Max. Chief Ray Angle | NA | |
| Coating Wavelength | 400-950 nm | |
|
|
||
|---|---|---|
| Mount | F-mount | |
| Filter Size | M62 × 0.75 | |
| Bulit-in IR-cut | NA | |
| Front/Rear Effective Dia. | NA | |
| Dimension | Φ73 × 42.65 mm | |
| Temperature Range | -10- 50°C（Working），-20- 60°C（Storage） | |
| Weight | NA | |
