General Information: |
||
|---|---|---|
| Model Number | VT-LEM2520 | |
| Series | CB Series | |
| Type | Standard FA Lens | |
|
|
||
|---|---|---|
| Resolution | 5 Mega Pixels | |
| Image Size | 1/1.8" CCD/CMOS | |
| Focal length | 25.0 mm | |
| Aperture, F/# | F2.0 | |
| Flange Back | 17.526mm | |
| Back Focus | 13.7mm | |
| M.O.D | 0.1 m | |
|
FOV(D×H×V) |
D:13.6° H:11.3° V:19° |
|
| TV Distortion | <0.1% | |
| TTL | 41.026 mm | |
| Relative Illumination | NA | |
| Focus Range | NA | |
| Iris | Manual | |
| Focus | Manual | |
| Max. Incident Angle | NA | |
| Coating Wavelength | 400-950nm | |
|
|
||
|---|---|---|
| Mount | C-mount | |
| Filter Size | M25.5× 0.5 | |
| Built-in ir-cut | NA | |
| Front/Rear Effective Dia. |
Front: Φ15.2; Rear: Φ6mm |
|
| Dimension | Φ27x23.5mm | |
| Temperature Range | -10- 50°C（Working），-20- 60°C（Storage） | |
| Weight | NA | |
