General Information |
||
|---|---|---|
| Model Number | CP-1200 | |
| Series | CB Series | |
| Type | Standard FA Lens | |
Optical Specifications |
||
|---|---|---|
| Resolution | 5 Mega Pixels | |
| Image Size | 1/1.8" CCD/CMOS | |
| Focal length | 8.0 mm | |
| Aperture, F/# | F2.0 | |
| Flange Back | 17.526 mm | |
| Back Focus | 11.4 mm | |
| M.O.D | 0.1 m | |
| FOV(D×H×V) |
D:46.8° H:36.0° V:56.0° |
|
| TV Distortion | <0.1% | |
| TTL | 42.526 mm | |
| Relative Illumination | NA | |
| Focus Range | NA | |
| Iris | Manual | |
| Focus | Manual | |
| Max. Incident Angle | NA | |
| Coating Wavelength | 400-950 nm | |
Mechanical Parameters |
||
|---|---|---|
| Mount | C-mount | |
| Filter Size | M25.5× 0.5 | |
| Built-in ir-cut | NA | |
| Front/Rear Effective Dia. | FrontΦ20.1 mm / RearΦ6 mm | |
| Dimension | Φ26.8 × 25 mm | |
| Temperature Range | -10 - 50°C（Working），-20 - 60°C（Storage） | |
| Weight | NA | |
