General Information: |
||
|---|---|---|
| Model Number | VT-LEM5020CD-H2 | |
| Series | CD Series | |
| Type |
Standard FA Lens
|
|
Optical Specifications |
||
|---|---|---|
| Resolution | 10 Mega Pixels | |
| Image Size | 4/3" CCD/CMOS | |
| Focal length | 50 mm | |
| Aperture, F/# | F2.0-22 | |
| Flange Back | 17.526mm | |
| Back Focus | 20.29 mm | |
| M.O.D | 0.3 m | |
|
FOV(D×H×V) |
D:25.9° H:20.9° V:15.7° |
|
| TV Distortion | -0.14%@y=11.5mm | |
| Relative Illumination | NA | |
| Focus Range | NA | |
| Iris | Manual | |
| Focus | Manual | |
| Max Chief Ray Angle | NA | |
| Coating Wavelength |
400-1100 nm
|
|
Mechanical Parameters: |
||
|---|---|---|
| Mount | C-mount | |
| Front/Rear Effective Dia. | NA | |
| Filter Thread | M40.5× 0.5 | |
| Dimension | Φ52.8 × 82.7 mm | |
| Temperature Range | -10- 50°C（Working），-20- 60°C（Storage） | |
| Weight | 170g | |
