Information |
||
|---|---|---|
| PD No. | iCt70CU200A-Pro | |
| PD Line | iCt Series | |
Sensor |
||
|---|---|---|
| Sensor Vendor | Onsemi | |
| Sensor | AR2020 | |
| Shutter | Rolling/GlobalResetRealease | |
| Sensor Size | 1/1.8" | |
| Sensor Type | CMOS | |
| Resolution | 5120*3840 | |
| Pixel Size | 1.4 μm | |
| Frame Rate | 19.6fps | |
| Color Type | Color | |
EMVA Data |
||
|---|---|---|
| Dynamic Range(typical) | 61 dB | |
| SNR(typical) | 39 dB | |
Camera Data |
||
|---|---|---|
| Interface | USB3.0 | |
| Image Format | Mono8/10/12, Bayer RG8/10/10Packed/12/12Packed,YUV422_8_UYVY,YUV422_8,RGB8,BGR8 | |
| Synchronization |
● Soft Trigger ● Hardware Trigger ● Free Run |
|
| I/O | 1× Opto-Isolated Input, 1× Opto-Isolated Output, 1× Configurable I/O (No Opto-Isolation) | |
| Power Supply | USB 3.0, DC9V~24V | |
Design |
||
|---|---|---|
| Dimension | 29mm×29mm×30mm(not including lens mount and rear case connector) | |
| Lens Mount | C-mount | |
| Working Temperature | -30 - 50°C(Operating), -30 - 80°C(Storage) | |
| Weight | 85g | |
Software Environment |
||
|---|---|---|
| Driver, SDK | iCentral or Third-party Software meeting with USB3 Vision Protocol | |
| Operating System | Windows，Linux | |
| Conformity | USB3 Vision and GenICam | |
