Information |
||
|---|---|---|
| PD No. | MARS25MG-41XM | |
| PD Line | Mars Series | |
Sensor |
||
|---|---|---|
| Sensor Vendor | GPixel | |
| Sensor | GMAX0505 | |
| Shutter | Global Shutter | |
| Sensor Size | 1.1" | |
| Sensor Type | CMOS | |
| Resolution | 5120 px x 5120 px | |
| Pixel size | 2.5 μm × 2.5 μm | |
| Frame Rate | 42 fps | |
| Mono/Color | Mono | |
EMVA Data |
||
|---|---|---|
| Dynamic range | 63.0 dB | |
| Signal-to-Noise Ratio (typical) | 36 dB | |
Camera Data |
||
|---|---|---|
| Interface | CoaXPress | |
| Pixel Bit Depth | 12 bits | |
| Synchronization |
● Soft Trigger ● Hardware Trigger ● Free Run |
|
| I/O | 1× Opto-isolated input, 1× Opto-isolated output, 1× configurable input and output | |
| Power Supply | 24 VDC / PoCXP | |
Design |
||
|---|---|---|
| Dimension (L x W x H) | 50 mm × 50 mm × 45 mm | |
| Lens Mount | C-mount | |
| Working Temperature | -30 - 50°C（Operating），-30 - 80°C（Storage） | |
Software Environment |
||
|---|---|---|
| Driver , SDK | Frame Grabber control software compliant with CoaXPress protocol | |
| Operating System | Windows | |
| Conformity | CoaxPress and GenICam | |
