Information |
||
|---|---|---|
| PD No. | MARS12MC-330XC-M58 | |
| PD Line | Mars Series | |
Sensor |
||
|---|---|---|
| Sensor Vendor | CMOSIS | |
| Sensor | CMV 12000 | |
| Shutter | Global Shutter | |
| Sensor Size | 22.5mm x 16.9mm | |
| Sensor Type | CMOS | |
| Resolution | 4092 px x 3072 px | |
| Pixel size | 5.5 μm x 5.5 μm | |
| Frame Rate | 330 fps | |
| Mono/Color | Color | |
EMVA Data |
||
|---|---|---|
| Dynamic range | 60.0 dB | |
| Signal-to-Noise Ratio (typical) | >41 dB | |
Camera Data |
||
|---|---|---|
| Interface | CoaXPress | |
| Pixel Bit Depth | 12 bits | |
| Synchronization |
● Soft Trigger ● Hardware Trigger ● Free Run |
|
| I/O | 3x Opto-isolated input, 3x Opto-isolated output;1x RS232 | |
| Power Supply | 24 VDC / PoCXP | |
Design |
||
|---|---|---|
| Dimension (L x W x H) | 80 mm x 80 mm x 72.3 mm | |
| Lens Mount | M58 x 0.75 | |
| Working Temperature | -30 - 50°C（Operating），-30 - 80°C（Storage） | |
Software Environment |
||
|---|---|---|
| Driver , SDK | Frame Grabber control software compliant with CoaXPress protocol | |
| Operating System | Windows | |
| Conformity | CoaxPress and GenICam | |
