Information |
||
---|---|---|
PD No. | CP-0823 | |
PD Line | LT3 Series |
Input Features |
||
---|---|---|
Input Voltage | AC100-240V 50/60Hz 350VA |
Output Features |
||
---|---|---|
Output Voltage | DC48V / 6A(6A per Channel) | |
Output Type | Constant Current | |
Output Power | ≤300W | |
Channel | 2 | |
Output port | 16M-6 | |
Light Control | Panel Button / Serial Port | |
Manual Adjustment Level | 256 Levels | |
Remote Control | RS232 Serial Communication |
Trigger Features |
||
---|---|---|
Trigger Delay | <150us | |
External Trigger Voltage | DC5V-24V(Maximum Current 5.6mA) |
Environment |
||
---|---|---|
Operating Environment |
Temperature:0 ~ 40℃ Humidity:20~85%RH (non-condensation) |
|
Storage Environment |
Temperature:-20~+60℃ Humidity:20~85%RH(non-condensation) |
Other |
||
---|---|---|
Cooling Method | Forced cooling |
