Information |
||
|---|---|---|
| PD No. | CP-0883 | |
| PD Line | Mars Series | |
Sensor |
||
|---|---|---|
| Sensor Vendor | Sony | |
| Sensor | IMX178 | |
| Shutter | Rolling Shutter | |
| Sensor Size | 1/1.8" | |
| Sensor Type | CMOS | |
| Resolution | 3072 px x 2048 px | |
| Pixel size | 2.4 μm x 2.4 μm | |
| Frame Rate | 18 fps | |
| Mono/Color | Mono | |
EMVA Data |
||
|---|---|---|
| Dynamic range | 60.0 dB | |
| Exposure time | 25 μs ~ 1 s | |
Camera Data |
||
|---|---|---|
| Interface | GigE | |
| Pixel Bit Depth | 8 / 10 / 12 bits | |
| Synchronization |
● Soft Trigger ● Hardware Trigger ● Free Run |
|
| I/O | 1 differential input; 1 I2C interface; 1 GPIO output | |
| Power Supply | PoE, DC6V~26V | |
Design |
||
|---|---|---|
| Design | Compact industrial design | |
| Dimension (L x W x H) | 55 mm x 55 mm x 14 mm | |
| Lens Mount | CS-Mount | |
| Working Temperature | -30 - 50°C（Operating），-30 - 80°C（Storage） | |
| Weight（Typical） | 60g | |
