General Information |
||
|---|---|---|
| PD No. | CP-1144 | |
| PD Line | CE Series | |
| Type |
Standard FA Lens
|
|
Optical Specifications |
||
|---|---|---|
| Resolution | 5 Mega Pixels | |
| Image Size | 1" CCD/CMOS | |
| Focal length | 22.0 mm | |
| Aperture, F/# | F2.0 | |
| Flange Back | 17.526 mm | |
| Back Focus | 20.3 mm | |
| M.O.D | 0.4 m | |
|
FOV(D×H×V) |
D:40.0° H:32° V:24° |
|
| TV Distortion | <1.0% | |
| TTL | 93.1 mm | |
| Relative Illumination | NA | |
| Focus Range | NA | |
| Iris | Manual | |
| Focus | Manual | |
| Max Chief Ray Angle | NA | |
| Coating Wavelength | 400-1100 nm | |
Mechanical Parameters |
||
|---|---|---|
| Mount | C-mount | |
| Filter Size | NA | |
| Built-in ir-cut | NA | |
| Front/Rear Effective Dia. | NA | |
| Dimension | Φ40 × 78.48 mm | |
| Temperature Range | -10- 50°C（Working），-20- 60°C（Storage） | |
| Weight | 220 g | |
