General Information: |
||
|---|---|---|
| Model Number | VT-LEM2516CD-H1 | |
| Series | CD Series | |
| Type | Standard FA Lens | |
|
|
||
|---|---|---|
| Resolution | 9 Mega Pixels | |
| Image Size | 1" CCD/CMOS | |
| Focal length | 25.0 mm | |
| Aperture, F/# | F1.6~22 | |
| Flange Back | 17.526mm | |
| Back Focus | 12.69mm | |
|
FOV(D×H×V) |
D:36.2° H:29.0° V:21.8° |
|
| TV Distortion | -2.06@y=8mm% | |
| TTL | 70.726 mm | |
| Relative Illumination | NA | |
| Focus Range | 1m-∞ | |
| Iris | Manual | |
| Focus | Manual | |
| Max. Incident Angle | NA | |
| Coating Wavelength | 400-1100 nm | |
|
|
||
|---|---|---|
| Mount | C-mount | |
| Filter Size | M39× 0.5 | |
| Built-in ir-cut | NA | |
| Front/Rear Effective Dia. | NA | |
| Dimension | Φ50.4 × 53.2 | |
| Temperature Range | -10- 50°C（Working），-20- 60°C（Storage） | |
| Weight | 157g | |
