General Information |
||
|---|---|---|
| Model Number | CP-1665 | |
| Series | CB Series | |
| Type | Standard FA Lens | |
|
|
||
|---|---|---|
| Resolution | 9 Mega Pixels | |
| Image Size | 1" CCD/CMOS | |
| Focal length | 20.0 mm | |
| Aperture, F/# | F1.6~22 | |
| Flange Back | 17.526mm | |
| Back Focus | 12.9mm | |
| M.O.D | 1.0 m | |
|
FOV(D×H×V) |
D:44.8° H:36.1° V:27.2° |
|
| TV Distortion | -2.83%@y=8.0mm | |
| TTL | 72.426 mm | |
| Relative Illumination | NA | |
| Focus Range | NA | |
| Iris | Manual | |
| Focus | Manual | |
| Max. Incident Angle | NA | |
| Coating Wavelength | 400-1100 nm | |
|
|
||
|---|---|---|
| Mount | C-mount | |
| Filter Size | M39× 0.5 | |
| Built-in ir-cut | NA | |
| Front/Rear Effective Dia. | NA | |
| Dimension | Φ48.9x54.9mm | |
| Temperature Range | -10- 50°C（Working），-20- 60°C（Storage） | |
| Weight | NA | |
