VT-LEM1614CB-H1
VT-LEM industrial lens is a high-performance and cost-effective product designed and manufactured by machine vision based on multi-year market application feedback, professional optical lens assembly and coating process, advanced optical structure, and performance and quality similar to foreign products. Comparable, the entire series reaches 5 million optical points.
Inquire now
Product Description
Technical Drawing
Documents & Downloads

General Information:

Model Number CP-1684
Series CB Series
Type Standard FA Lens


Optical Specifications

Resolution 8 Mega Pixels
Image Size 1" CCD/CMOS
Focal length 16.0 mm
Aperture, F/# F1.4~1.6
Flange Back 17.526mm
Back Focus 22.75mm
M.O.D 0.1 m
FOV(D×H×V)

D:51.6°

H:42.4°

V:32.4°

TV Distortion 0.2%
TTL 75.926 mm
Relative Illumination NA
Focus Range NA
Iris Manual
Focus Manual
Max. Incident Angle NA
Coating Wavelength 400-1100 nm


Mechanical Parameters:

Mount C-mount
Filter Size M46× 0.75
Built-in ir-cut NA
Front/Rear Effective Dia. Front: Φ35.3 mm / Rear: Φ11.5 mm
Dimension Φ50 × 58.2±0.2 mm
Temperature Range -10- 50°C(Working),-20- 60°C(Storage)
Weight NA

Standard FA industrial lens


-->
