Information |
||
|---|---|---|
| PD No. | iBOOSTX-71USW500M-SA | |
| PD Line | iBoostX Series | |
Sensor |
||
|---|---|---|
| Sensor Type | InGaAs | |
| Sensor | Sony IMX992-AABA-C Buit-in TEC | |
| Sensor Size | 1/1.4" | |
| Resolution | 2560× 2048 | |
| Pixel Size | 3.45 x 3.45 μm | |
| Frame Rate [Fps] |
8-Bit:61.9@2560x2048 / 135.7@1280x1024 12-Bit:35.5@2560x2048 / 135.7@1280x1024 |
|
| Exposure time | 15μs-60s | |
| Spectral Range | 0.4μm - 1.8μm | |
EMVA Data |
||
|---|---|---|
| Dynamic range | 51.36dB(HCG) 51.47dB(LCG) | |
| SNR | 46.17dB(HCG) 48.45dB(LCG) | |
| Sensitivity | TBD | |
| Dark current | TBD | |
Camera Data |
||
|---|---|---|
| Interface | USB3.0 | |
| Pixel Bit Depth | 8 Bit / 12 Bit | |
| I/O | One opto-isolated input, one opto-isolated output, two non-isolated input and output | |
| Power Supply | DC12V | |
Design |
||
|---|---|---|
| Dimension | 80 × 80 × 45.5 mm (<390g) | |
| Lens Mount | C-mount | |
| Operating Temperature | -40~85 °C (Storage), -20~60°C (Working) | |
Software Environment |
||
|---|---|---|
| Operating System | Windows，Linux | |
