Information |
||
|---|---|---|
| PD No. | iBX-SWU990J | |
| PD Line | iBoostX | |
Sensor |
||
|---|---|---|
| Sensor | InGaAs | |
| Resolution | 1280 × 1024 | |
| Frame Rate | 12Bit:108fps@1280 x 1024 209fps@640X 512 8 Bit: 200fps@1280 x 1024 392fps@640X 512 | |
| Pixel Size | 5 μm | |
| Optical Size | 1/2" | |
| Spectral Band | 0.4-1.8um | |
| Dynamic Range(typical) | 58.7dB | |
| Exposure Time | 15μs-60s | |
Camera Data |
||
|---|---|---|
| Interface | USB3.0 | |
| Pixel Bit Depth | 8/12bit | |
| I/O | 1 opto-isolated input, 1 opto-isolated output, 2 non-isolated I/O | |
| Input Supply Voltage | USB3 / 12V | |
Design |
||
|---|---|---|
| Weight | <390 g | |
| Dimension | 80mm × 80mm × 45.5mm | |
| Lens Mount | C-Mount | |
Environment Adaptability |
||
|---|---|---|
| Temperature | -20 °C ~ +60 °C（Operating）-40 °C ~ +85 °C（Storage） | |
| Humidity | 20%~80% (non-condensing) | |
