General Information: |
||
---|---|---|
Model Number | CP-1231 | |
Series | CB Series | |
Type | Standard FA Lens |
|
||
---|---|---|
Resolution | 2 Mega Pixels | |
Image Size | 2/3" CCD/CMOS | |
Focal length | 100.0 mm | |
Aperture, F/# | F2.8-16 | |
Flange Back | 17.526mm | |
Back Focus | 12.7mm | |
M.O.D | >2.0 m | |
FOV(D×H×V) |
D:5.6° H:7.5°
|
|
TV Distortion | 0.1% | |
TTL | 83.386mm | |
Relative Illumination | NA | |
Focus Range | NA | |
Iris | Manual | |
Focus | Manual | |
Max. Incident Angle | NA | |
Coating Wavelength | 400-1100 nm |
|
||
---|---|---|
Mount | C-mount | |
Filter Size | M37.5× 0.5 | |
Built-in ir-cut | NA | |
Front/Rear Effective Dia. |
Front: Φ19; Rear: Φ14.2mm |
|
Dimension | Φ39x65.86mm | |
Temperature Range | -10- 50°C(Working),-20- 60°C(Storage) | |
Weight | NA |
