General Information: |
||
|---|---|---|
| Model Number | CP-0752 | |
| Series | CB Series | |
| Type | Standard FA Lens | |
|
|
||
|---|---|---|
| Resolution | 8 Mega Pixels | |
| Image Size | 1" CCD/CMOS | |
| Focal length | 35.0 mm | |
| Aperture, F/# | F1.4~16 | |
| Flange Back | 17.526mm | |
| Back Focus | 11.2mm | |
| M.O.D | 0.15 m | |
|
FOV(D×H×V) |
D:23.92° H:19.28° V:14.32° |
|
| TV Distortion | 0.1% | |
| TTL | 70.726 mm | |
| Relative Illumination | NA | |
| Focus Range | NA | |
| Iris | Manual | |
| Focus | Manual | |
| Max. Incident Angle | NA | |
| Coating Wavelength | 400-1100 nm | |
|
|
||
|---|---|---|
| Mount | C-mount | |
| Filter Size | M46× 0.75 | |
| Built-in ir-cut | NA | |
| Front/Rear Effective Dia. | Front: Φ27 mm / Rear: Φ17 mm | |
| Dimension | Φ52 × 53±0.2 mm | |
| Temperature Range | -10- 50°C（Working），-20- 60°C（Storage） | |
| Weight | NA | |
