General Information |
||
|---|---|---|
| PD No. | VT-LEN2014MP12-H1.1 | |
| PD Line | LEN Series | |
Optical Specifications |
||
|---|---|---|
| Resolution | 12 Mega Pixels | |
| Image Size | 1.1'' | |
| Focal Length | 20±5%mm | |
| Aperture, F/# | F1.4±5% | |
| Flange Back | 17.526mm | |
| Back Focus | 12.474mm (in air) | |
| M.O.D | 0.5m | |
| FOV | 49.06° ×42.4° ×27.96° | |
| TV Distortion | <4.50% | |
| Iris | Manual | |
| Focus | Manual | |
| Coating Wavelength | 420-650nm | |
Design |
||
|---|---|---|
| Lens Mount | C-Mount | |
| Filter Size | M41*0.5 | |
| Temperature | -30℃～ +70℃ | |
| Weight | 212±5g | |
