Information |
||
|---|---|---|
| PD No. | GAL4K-40CCNIR | |
| PD Line | GAL Series | |
Sensor |
||
|---|---|---|
| Sensor Size [mm] | 28.6 | |
| Sensor Type | CMOS | |
| Resolution | 4096 px x 4 px | |
| Pixel size | 7 μm x 7 μm | |
| Line Rate [KHz] | 40 | |
| Color | RGB/NIR | |
| Pixel Clock | 85M hz/65M hz | |
EMVA Data |
||
|---|---|---|
| Dynamic range | 74.0 dB | |
| Sensitivity | 33.5V/lux*s | |
Camera Data |
||
|---|---|---|
| Interface | Cameralink（SDR） | |
| Pixel Bit Depth | 8bits | |
| Synchronization | Via hardware trigger or free run mode | |
| Configuration Mode | Base、Dual Base、Medium or Full | |
| Power Input | PoCL/12-24V <4W | |
Design |
||
|---|---|---|
| Dimension | 46 × 46 × 41 mm(250g) | |
| Lens Mount | M42*1, FBL:12±0.15mm | |
| Working Temperature | 0- 60°C(Working) | |
Software Environment |
||
|---|---|---|
| Conformity | Camera Link | |
| Operating System | Windows | |
