VT-LEN0828MP25-H1.1
1. 1.1' C-MOUNT FIXED LENSES(20-25MP).
2. High resolution at whole range of WD and excellent brightness.
3. Robust design, suitable for most machine vision applications.
4. Professional MTF optimization
5. Lockable focus and iris screws prevent movement during vibrations or shocks.
6. High cost-performance ratio
Inquire now
Product Description
Technical Drawing
Documents & Downloads

General Information

Model Number VT-LEN0828MP25-H1.1
Series VT-LEN Series
Type Standard FA Lens

Optical Specifications

Resolution 25 Mega Pixels
Image Size 1.1" CCD/CMOS
Focal length 8.0 mm
Aperture, F/# F2.8-22
Flange Back 17.526 mm
M.O.D 0.1 m
FOV

2/3":55.2°×47.5°

1":70.35°×70.35°

1.1":82.8°×65.8°

TV Distortion <3%
Iris Manual
Focus Manual

Design

Mount C-mount
Filter Size NA
Built-in ir-cut NA
Dimension Φ60.8 × 70.97 mm
Temperature Range -10- 50°C(Working),-20- 60°C(Storage)
Weight 337g

Standard FA industrial lens


-->
