iBOOST01-74UUVC410M
■ Scientific grade professional cameras based on GSENSE series full frame or large pixel sensitive chips;
■ High-speed USB3.0/Camera Link interface optional,transmission speed up to 5Gbits/s;
■ IR-CUT or double AR film protective glass (optional);

■ Support up to 1 hour accurate exposure control technology;

■ Two-stage professional design of high-performance TE cooling structure, smart structure, fast cooling speed;
■ Built-in ISP module up to 16bit;

■ Ultra-Fine color processing engine for perfect color reproduction function;
■ Built-in 2D denoising function and sharpening function;
Inquire now
Product Description
Technical Drawing
Documents & Downloads

Information

PD No. iBoost01-74UUVC410M
PD Line iBoost01 Series

Sensor

Sensor type InGaAs
Sensor 4.2MP / GSENSE2020BSI(M,UV,RS)
Sensor Size 1.2"(13.31x13.31)
Resolution 2048 x 2048
Pixel Size 6.5 x 6.5 μm
FPS 74@2048 x2048(11-bit ADC)
74@1024 x1024(11-bit ADC)
G light sensitivity 1.1x108(e-/((W/m2).s))Peak QE 94% @550nm
Dark current 0.21(e-/s/pix) @-20C
Spectral Range 200-1100nm

EMVA Data

Dynamic range (typical) 65.58dB
Signal-to-Noise Ratio (typical) 34.83dB
Exposure Time 12μs~1h

Camera Data

Interface USB3.0
Pixel Bit Depth 8 Bit / HDR 16 Bit
I/O 1 opto-coupler isolated input, 1 opto-coupler isolated output, 2 GPIOs
Power Supply DC12V,3A

Design

Dimension 80mm×80mm×107mm
Lens Mount C-mount
Operating Temperature -10~ 50℃ (Working),-20~ 60℃ (Storage)

Software Environment

Operating System Windows 7 / 8 /10 /11(32 & 64 位),Mac OS,Linux

iBoost01 Series Industrial Cameras SDK

iBoost01 Series Industrial Cameras User Manua

Product Specification


-->
