Information |
||
|---|---|---|
| PD No. | MARS3000S-120UC-BC | |
| PD Line | Mars Series | |
Sensor |
||
|---|---|---|
| Sensor Vendor | Sony | |
| Sensor | IMX252 | |
| Shutter | Global Shutter | |
| Sensor Size | 1/1.8" | |
| Sensor Type | CMOS | |
| Resolution | 2048 px × 1536 px | |
| Pixel size | 3.45 μm × 3.45 μm | |
| Frame Rate | 120 fps | |
| Mono/Color | Color | |
EMVA Data |
||
|---|---|---|
| Dynamic range | >70.0 dB | |
| Exposure time | 16 μs ~ 1 s | |
Camera Data |
||
|---|---|---|
| Interface | USB3.0 | |
| Pixel Bit Depth | 10 bits | |
| Synchronization |
● Soft Trigger ● Hardware Trigger ● Free Run |
|
| I/O | 1 opto-isolated input lines, 1 opto-isolated output lines, 1 non-opto-isolated Configurable input and output lines | |
| Power Supply | 5V via USB3.0 port | |
Design |
||
|---|---|---|
| Design | Compact industrial design | |
| Dimension (L x W x H) | 35 mm x 35 mm x 31 mm | |
| Lens Mount | C-Mount | |
| Working Temperature | -30 - 50°C（Operating），-30 - 80°C（Storage） | |
| Weight（Typical） | 50g | |
