Information |
||
|---|---|---|
| PD No. | MARS25MG-30CC | |
| PD Line | Mars Series | |
Sensor |
||
|---|---|---|
| Sensor Vendor | Gpixel | |
| Sensor | - | |
| Shutter | Global Shutter | |
| Sensor Size | 1.1" | |
| Sensor Type | CMOS | |
| Resolution | 5120 px x 5120 px | |
| Pixel size | 2.5 μm × 2.5 μm | |
| Frame Rate | 30 fps | |
| Mono/Color | Color | |
EMVA Data |
||
|---|---|---|
| Dynamic range | >64.0 dB | |
| Signal-to-Noise Ratio (typical) | >35.0 dB | |
Camera Data |
||
|---|---|---|
| Interface | Cameralink | |
| Pixel Bit Depth | 10 bits | |
| Synchronization |
● Soft Trigger ● Hardware Trigger ● Free Run |
|
| I/O | Opto-isolated input x 1, opto-isolated output x 1, and bi-directional custom non-isolated I/O x 1 | |
| Power Supply | PoCL，DC 9-24V | |
Design |
||
|---|---|---|
| Design | Compact industrial design | |
| Dimension (L x W x H) | 29.0 × 44.0 × 58.0 mm | |
| Lens Mount | C-mount | |
| Working Temperature | -30 - 50°C（Operating），-30 - 80°C（Storage） | |
| Weight（Typical） | 100g | |
Software Environment |
||
|---|---|---|
| Driver , SDK | Mars Series Camera Software Suite (iCentral) or 3rd Party Cameralink Protocol Software | |
| Operating System | Windows | |
| Conformity | Cameralink and GenICam | |
