Information |
||
|---|---|---|
| PD No. | LEO 5000S-60UC-BC | |
| PD Line | LEO Series | |
Sensor |
||
|---|---|---|
| Sensor Vendor | Sony | |
| Sensor | IMX 264 | |
| Shutter | Global Shutter | |
| Sensor Size | 2/3" | |
| Sensor Type | CMOS | |
| Resolution | 2448 × 2048 | |
| Pixel size | 3.45 μm x 3.45 μm | |
| Frame Rate | 60 fps | |
| Mono/Color | Color | |
EMVA Data |
||
|---|---|---|
| Dynamic range | 72.0 dB | |
| Exposure time | 15 μs ~ 10 s;UltraShort exposure mode(1 μs to 14 μs) | |
Camera Data |
||
|---|---|---|
| Interface | USB3.0 | |
| Pixel Bit Depth | 8 / 10 / 12 bits | |
| Synchronization |
● Soft Trigger ● Hardware Trigger ● Free Run |
|
| I/O | 2 bidirectional configurable I/O(without opto-isolated) | |
| Power Supply | 5 VDC | |
Design |
||
|---|---|---|
| Design | Compact industrial design | |
| Dimension (L x W x H) | 29 mm × 29 mm × 31.3 mm | |
| Lens Mount | C-Mount | |
| Working Temperature | 0- 50°C（Operating），-30- 70°C（Storage） | |
| Weight | 37g | |
