LEO 1440S-65gm-BLW
■ Global , rolling shutter exposure CMOS
■ Super cost-effective
■ Follow GigE Vision, USB3 Vision protocol and GenICam standard
■ Support PoE power supply (specific models)
Inquire now
Product Description
Technical Drawing
Documents & Downloads

Information

PD No. CP-0883
PD Line LEO Series

Sensor

Sensor Vendor Sony
Sensor IMX 296
Shutter Global Shutter
Sensor Size 1/2.9"
Sensor Type CMOS
Resolution 1440 px x 1080 px
Pixel size 3.45 μm x 3.45 μm
Frame Rate 65.2 fps
Mono/Color Mono

EMVA Data

Dynamic range >74.0 dB
Exposure time 超短曝光模式:1 μs ~ 14 μs; 标准曝光模式:15 μs ~ 10 sec

Camera Data

Interface WTB
Pixel Bit Depth 8 / 10 / 12 bits
Synchronization

● Soft Trigger

● Hardware Trigger

● Free Run

I/O 1 bidirectional configurable I/O(without opto-isolated)
Power Supply 24 VDC

Design

Design Compact industrial design
Dimension (L x W x H) 29 mm × 29 mm × 21.2 mm
Lens Mount M12-Mount
Working Temperature 0- 50°C(Operating),-30- 70°C(Storage)
Weight 25g
