Information |
||
|---|---|---|
| PD No. | CP-1608 | |
| PD Line | BTL Series | |
| Type | Bi-Telecentric Lenses | |
Lens Data |
||
|---|---|---|
| FOV | 36 Φmm | |
| Mag.(x) | 0.200x | |
| WD | 110±2 mm | |
| Max. Sesnor Size | 8.0(1/2") Φmm | |
| F/# | F4.2 | |
| MTF | >190lp/mm | |
| D.O.F | ±8.9 mm@F11 | |
| Distortion | <0.1% | |
| Telecentricity | <0.1° | |
| I/O | 255±2 mm | |
Design |
||
|---|---|---|
| Lens Mount | C-mount | |
| Length | 127.2 mm | |
| Temperature | -10 - 50°C（Operating），-20 - 60°C（Storage） | |
| Weight | 0.4 Kg | |
