VT-LEM-03618(i)-M12-MP
1. Megapixel High Resolution Design
2. Optimized for 1/3” and ?” Sensors with Small Pixels
3. Multiple f/# Options for Performance
4. High Cost Performance
Inquire now
Product Description
Product parameters
Product Specifications

General Information

PD No. CP-659
PD Line M12 Series
Type Standard FA Lens


Optical Specifications

Resolution 1 Mega Pixels
Image Size 1/3" CCD/CMOS
Focal length 3.6 mm
Aperture, F/# F1.8
Back Focus 6.59 mm
M.O.D 0.2 m
FOV(D×H×V)

D:100.2°

H:77°

V:54°

TV Distortion <-0.29%
TTL 22.81 mm
Relative Illumination NA
Focus Range NA
Iris Manual
Focus Manual
Max Chief Ray Angle NA
Coating Wavelength 400-950 nm


Mechanical Parameters

Mount S-mount(M12)
Filter Size NA
Built-in ir-cut NA
Front/Rear Effective Dia. Front:Φ18.2 mm / Rear:Φ9 mm
Dimension Φ29 × 37.94 mm
Temperature Range -10- 50°C(Working),-20- 60°C(Storage)
Weight NA

Standard FA industrial lens

-->
