General Information |
||
|---|---|---|
| PD No. | CP-1721 | |
| PD Line | Large format | |
| Type | Large format F/T Mount lens | |
|
|
||
|---|---|---|
| Resolution | 29MP | |
| Format | 58mm | |
| Focal Length | 80.0 mm | |
| Aperature, F/# | F5.6 | |
| Mag. Range | 0.2x-0.4x | |
| Standard Mag. | 0.3x | |
| Flange Back | 46.5 | |
|
|
|
|
|
Object Distance M.O.D. |
306.2mm NA |
|
|
|
|
|
| TV Distortion | <0.03% | |
| TTL | 137.5 | |
| Relative Illumination | NA | |
| Focus Range | NA | |
| Iris | Manual | |
| Focus | Manual | |
| Max. Chief Ray Angle | NA | |
| Coating Wavelength | 400-950 nm | |
|
|
||
|---|---|---|
| Mount | F-mount | |
| Filter Size | M52 × 0.75 | |
| Bulit-in IR-cut | NA | |
| Front/Rear Effective Dia. | NA | |
| Dimension | Φ57× 91 mm | |
| Temperature Range | -10- 50°C（Working），-20- 60°C（Storage） | |
| Weight | NA | |
