Information |
||
|---|---|---|
| PD No. | DM-J160U-MxxAF-SRST | |
| PD Line | DataMagic Series | |
Performance |
||
|---|---|---|
| Symbologies |
1D：Code 39，Code 93，Code 128，CodaBar，EAN8，EAN13，ITF25，ITF14，MATRIX25，UPCA，UPCE，MSI，CODE11，INDUSTRIAL25，CHINAPOST，PHARMACODE 2D：QR Code，Data Matrix，Micro QR Stack codes：PDF417 |
|
| Frame Rate | 60 fps | |
| Reading Speed | 110 codes/sec | |
| Sensor size | 1/2.9” | |
| Sensor type | CMOS, Global Shutter | |
| Resolution | 1408 × 1024 px | |
| Pixel size | 3.45 μm x 3.45 μm | |
| Exposure time | 6μs ~ 30000μs | |
| Mono/color | Mono | |
| Focal length | 8/12/25mm optional | |
| Protocols | SmartSDK，TCP Client，Serial，FTP，TCP Server，Melsec/SLMP，Modbus，FINS，UDP | |
Electrical Data |
||
|---|---|---|
| Data interface | Fast Ethernet（100 Mbit/s） | |
| I/O | 3 non-isolated input, 3 non-isolated output, 1 RS-232 | |
| Power | 24 V | |
| Power Consumption | 6.2 W@24V | |
Design |
||
|---|---|---|
| Protection | IP67 | |
| Dimensions |
Straight angle：80.1 mm × 43 mm × 44.3 mm Right angle：58.5 mm × 43 mm × 65.4 mm |
|
| Lens | M12-Mount,mechanical autofocus supported. | |
| Lighting | Spotlight red light and white diffuse light;Spotlight white/blue/IR, is optional | |
| Lens cap | Transparent + Polarization + Diffusion lens cap.(optional) | |
| Working Temperature | 0- 50°C（Operating），-30- 70°C（Storage） | |
| Weight（Typical） | 195g | |
Software Environment |
||
|---|---|---|
| Driver , SDK | DM-Datum | |
