Information |
||
|---|---|---|
| PD No. | LEO 5000S-23GM-CS | |
| PD Line | LEO Series | |
Sensor |
||
|---|---|---|
| Sensor Vendor | Sony | |
| Sensor | IMX 264 | |
| Shutter | Global Shutter | |
| Sensor Size | 2/3" | |
| Sensor Type | CMOS | |
| Resolution | 2448 px x 2048 px | |
| Pixel size | 3.45 μm x 3.45 μm | |
| Frame Rate | 23.5 fps | |
| Mono/Color | Mono | |
| Image Format | Mono8/10/10p/12/12p | |
| Exposure Time | 20μs~10s | |
EMVA Data |
||
|---|---|---|
| Dynamic range | 72.0 dB | |
| Signal-to-Noise Ratio (typical) | 40.2 dB | |
Camera Data |
||
|---|---|---|
| Interface | GigE | |
| Synchronization |
● Soft Trigger ● Hardware Trigger ● Free Run |
|
| I/O | 1 input(opto-isolated)，1 output(opto-isolated) | |
| Power Supply | 12 VDC | |
Design |
||
|---|---|---|
| Design | Compact industrial design | |
| Dimension (L x W x H) | 51.1 × 36.5 × 79.7 mm | |
| Lens Mount | CS-Mount (Supports Auto-iris) | |
| Working Temperature | 0 - 50°C（Operating），-30 - 70°C（Storage） | |
| Weight（Typical） | 165g | |
Software Environment |
||
|---|---|---|
| Driver , SDK | LEO Series Camera Secondary Development Kit（iDatum）or Third-party Software meeting with GigE Vision Protocol | |
| Operating System | Windows，Linux | |
| Conformity | GigE Vision and GenICam | |
