Information |
||
|---|---|---|
| PD No. | DM-W160S-M0CM-00ST | |
| PD Line | DataMagic Series | |
Performance |
||
|---|---|---|
| Symbologies |
1D：：Code 39，Code 93，Code 128，ITF14，ITF25，CodaBar，EAN8，EAN13，UPCA，UPCE... 2D：QR Code，Data Matrix... |
|
| Frame Rate | 60 fps | |
| Reading Speed | 45 codes/sec | |
| Sensor size | 1/2.9” | |
| Sensor type | CMOS, Global Shutter | |
| Resolution | 1408 × 1024 px | |
| Pixel size | 3.45 μm × 3.45 μm | |
| Protocols | Serial, TCP Client, SLMP, Modbus，TCP Server, FTP, UDP, Fins, MELSEC | |
Electrical Data |
||
|---|---|---|
| Data interface | Fast Ethernet（100 Mbit/s） | |
| I/O | 1 non-isolated input, 1 non-isolated output.2 bi-directional none-isolated I/O，1 RS-232 | |
| Power | 12 ~ 24 VDC | |
| Power Consumption | 6 W@12V | |
Design |
||
|---|---|---|
| Protection | IP40 | |
| Dimensions | 29 mm × 29 mm × 42 mm | |
| Lens | C-Mount | |
| Working Temperature | 0- 50°C（Operating），-30- 70°C（Storage） | |
| Weight（Typical） | 140g | |
Software Environment |
||
|---|---|---|
| Driver , SDK | DM-Datum | |
