Information |
||
|---|---|---|
| PD No. | DM-Q300S-MxxSM-SWST | |
| PD Line | DataMagic Series | |
Performance |
||
|---|---|---|
| Symbologies |
1D：Code 39，Code 93，Code 128，CodaBar，EAN8，EAN13，UPCA，UPCE，ITF14，Matrix 2 of 5，Matrix 25，MSI，China Post，Code 11，Industrial 25 2D：QR Code，Data Matrix Stack codes：PDF417 |
|
| Frame Rate | 60 fps | |
| Reading Speed | 90 codes/sec | |
| Sensor size | 1/2” | |
| Sensor type | CMOS, Global Shutter | |
| Resolution | 2048 × 1536 px | |
| Pixel size | 2.5 μm x 2.5 μm | |
| Exposure time | 16μs ~ 1s | |
| Mono/color | Mono | |
| Focal length | 8/12/16/25mm optional | |
| Protocols | Serial,TCP Client,TCP Server,FTP,ModBus,Fins,SLMP,MELSEC | |
Electrical Data |
||
|---|---|---|
| Data interface | Fast Ethernet（100 Mbit/s） | |
| I/O | 3 non-isolated input, 3 non-isolated output, 1 RS-232 | |
| Power | 24 V | |
| Power Consumption | 60 W@24V | |
Design |
||
|---|---|---|
| Protection | IP67 | |
| Dimensions | 112.5 mm × 65.5 mm × 63.3 mm | |
| Lens | M12-Mount,mechanical autofocus | |
| Lighting | Integrated LEDs, red/white/blue/NIR light optional | |
| Lens cap | Half polarized(Polarized and transparent optional) | |
| Working Temperature | 0- 50°C（Operating），-30- 70°C（Storage） | |
| Weight（Typical | 450g | |
Software Environment |
||
|---|---|---|
| Driver , SDK | DM-Datum | |
