Information |
||
|---|---|---|
| PD No. | VT-SM2-1408SE-C08 | |
| PD Line | SM2 Series | |
Tools |
||
|---|---|---|
| Vision Tool | Existence、Count、Positioning、Logic、Measurement、Recognition | |
| Solution Capacity | Supports solution importing and exporting, up to 8 solutions and 40 modules can be stored. | |
| Communication Protocol | RS-232、TCP、UDP、FTP、Modbus | |
Sensor |
||
|---|---|---|
| Sensor Type | CMOS | |
| Sensor Size | 1/2.9” | |
| Shutter | Global Shutter | |
| Resolution | 1408 px x 1024 px | |
| Pixel size | 3.45 μm x 3.45 μm | |
| Frame Rate | 60 fps | |
| Mono/Color | Color | |
| Image Format | Mono 8、RGB 8 | |
| Exposure Time | 16 μs ~ 1 sec | |
Camera Data |
||
|---|---|---|
| Ethernet | Fast Ethernet（100Mbit/s） | |
| Digital I/O | 17-pin M12 connector provides power and I/O, including 1 input, 2 configurable I/Os, 1 output; 1 RS-232 | |
| Power Consumption | 12 ~ 24 VDC | |
Design |
||
|---|---|---|
| Dimension | 46 × 57.6 × 25 mm | |
| Lens Mount | M12-Mount,Manual Focus | |
| Focal Length | 8mm | |
| Lens Cap | Transparent lens cap | |
| Light Source | White | |
| Temperature | 0- 50°C（Working），-30- 70°C（Storage） | |
| Weight | 220g | |
Software Environment |
||
|---|---|---|
| Driver , SDK | LEO SM Series Camera Secondary Development Kit（SM-Datum） | |
| Operating System | Windows | |
